Anvil® Swivel Ring, Adjustable Split, Series: FIG 104, 1-1/2 in Pipe, 3/8 in Rod, 300 lb, For Use With: Non-Insulated Stationary Pipe Line, Malleable Iron, Zinc Plated, 2-1/16 in ID, 450 deg F
Dimensions
2-1/16 in ID
Finish
Zinc Plated
Load Capacity
300 lb
Material
Malleable Iron
Pipe Size
1-1/2 in
Rod Size
3/8 in
Series
FIG 104
Suitable For Use With
Non-Insulated Stationary Pipe Line
Temperature Rating
450 deg F
Type
Adjustable Split
- Adjustable swivel ring is self-locking; prevents loosening due to vibration; maintains proper pitch of pipe.
- Labor-saving features in installation completely outweigh slight additional cost
- Hanger may be installed prior to suspension of pipe
- Off-center hinge provides seating for pipe during installation
- Wedge-type locking pin is inseparably cast into hinged section, sizes 2-1/2 in and larger
- Adjustable swivel ring is self-locking, prevents loosening due to vibration, maintains proper pitch of pipe
- Wire retaining ring prevents separation of swivel shank from pipe ring before installation
