The Apollo® RVW62 is an ASME section IV capacity certified bronze safety relief valve for protection of hot water heating boilers, swimming pool heaters and similar equipment. It can be pre-set to any pressure ranging between 30 to 150 psig (2.1 to 10.3 bar) and 250 deg F (121 deg C).
Apollo™, 1062490, Safety Relief Valve, High Capacity, Series: 10-620, 3/4 in Nominal, NPT End Style, 90 psi Set Pressure, 250 deg F, Lift Handle Actuator, Bronze Body, Silicon Seat Softgoods, 4.62 in H Dimensions, Domestic
Actuator Type
Lift Handle
Body Material
Bronze
Dimensions
4.62 in H
Domestic/Import
Domestic
End Style
NPT
Nominal Size
3/4 in
Series
10-620
Set Pressure
90 psi
Softgoods Material
Silicon Seat
Temperature Rating
250 deg F
Type
High Capacity
- Corrosion resistant construction
- Diaphragm isolated spring chamber
