The Apollo™ 82-200 and 82A240 series is an in-line serviceable valve designed for soft soldering or brazed installations. SAE Grade Body Bolts and RPTFE seals are standard.
Apollo™, 8224401, Ball Valve, 3-Piece, Series: 82-200, 3/4 in Nominal, Solder End Style, 600 psi CWP Pressure, 350 deg F, Full Port, Media: Gas/Water, 0.83 in Orifice, Standard Lever Actuator, Stainless Steel Ball, 3.43 in Inlet to Outlet Length, 2.18 in Top to Inlet Center, Bronze Body, 316 Stainless Steel Stem/RPTFE Seat Trim, RPTFE Softgoods
Actuator Type
Standard Lever
Ball Material
Stainless Steel
Body Material
Bronze
Domestic/Import
Domestic
End Style
Solder
Inlet to Outlet Length
3.43 in
Media
Gas/Water
Nominal Size
3/4 in
Orifice Size
0.83 in
Port Type
Full
Pressure Rating
600 psi CWP
Series
82-200
Softgoods Material
RPTFE
Temperature Rating
350 deg F
Top to Inlet Center
2.18 in
Trim Material
316 Stainless Steel Stem/RPTFE Seat
Type
3-Piece
- Blow-out proof stem
- Premium RPTFE seats and seal
- Vacuum service to 29 in Hg
- 150 psi working steam pressure
