Designed and manufactured for the ultimate in durability and reliability, the new Apollo™ pneumatic rack and pinion actuators provide outstanding service life. Apollo™ rack and pinion actuators have replaceable insert drive adapters in all but the largest Models, and many units have dual F series bolt patterns. The numerous actuator drive and bolt pattern combinations allow direct mounting of several valve styles.
Apollo™, AS0065N04ACA, Pneumatic Actuator, Quarter-Turn Rack and Pinion, Series: AS, 0065 Actuator, 90 deg Stroke, 41 to 15867 lbf-in Output Torque, Spring Return Valve Design, +/- 4 deg Travel Adjustment, 0.7 s Opening/0.5 s Closing Timing, 43.5 to 120 psi Pressure, -4 to 176 deg F, Top Mounting, Cast Aluminum Alloy Body, Steel Trim, Nitrile Softgoods, Yellow Polyurethane Powder Coated, Import
- Die cast aluminum end caps
- Hard anodized die cast aluminum pistons
- Hard-coat anodized finished aluminum alloy pinion
- Hard-coat anodized finished extruded alumnium drive inserts
- Delta-Tone coated preloaded concentric springs
- Polyoxymethylene (pom) bushings
- Stainless steel or Delta-Tone coated capscrews, nuts and other hardware
- Steel spring
- Nitrile seal
- -4 to 175 deg F normal temperature nitrile
- (4) spring set
- Fail closed
- Revision A
