Sharpe® Gate Valve, Series: 35116, 4 in Nominal, Flanged End Style, 275 psi Pressure, 150 lb Pressure Class, -20 to 1000 deg F, Full Port, Handwheel Actuator, 9.02 in Inlet to Outlet Length, 21.45 in Top to Inlet Center, 316 Stainless Steel Body, Stainless Steel Trim, PTFE Gland Packing Gasket Softgoods, 9.84 in Diameter Hand Wheel
Actuator Type
Handwheel
Body Material
316 Stainless Steel
End Style
Flanged
Hand Wheel Diameter
9.84 in
Inlet to Outlet Length
9.02 in
Nominal Size
4 in
Port Type
Full
Pressure Class
150 lb
Pressure Rating
275 psi
Series
35116
Softgoods Material
PTFE Gland Packing Gasket
Temperature Rating
-20 to 1000 deg F
Top to Inlet Center
21.45 in
Trim Material
Stainless Steel
- Outside screw and yoke
- Bolted bonnet
- Flexible wedge, fully guided
- Integrated seat
- Rising stem and non-rising handwheel
- Available with gear operator
