Sharpe® Globe Valve, Series: 40276, 1-1/4 in Nominal, FNPT End Style, 200 lb Pressure Class, 0 to 350 deg F, Handwheel Actuator, 4.13 in Inlet to Outlet Length, 4.49 in Top to Inlet Center, 316 Stainless Steel Body, 316 Stainless Steel Trim, PTFE Seal Softgoods, 3.12 in Diameter Hand Wheel
Actuator Type
Handwheel
Body Material
316 Stainless Steel
End Style
FNPT
Hand Wheel Diameter
3.12 in
Inlet to Outlet Length
4.13 in
Nominal Size
1-1/4 in
Pressure Class
200 lb
Series
40276
Softgoods Material
PTFE Seal
Temperature Rating
0 to 350 deg F
Top to Inlet Center
4.49 in
Trim Material
316 Stainless Steel
- Threaded in bonnet
- Non-rising stem
- Hydrostatic shell test at 300 psi
