Watson McDaniel, 455-12-N-62, Valve, Direct-Operated, Series: 455, 1/2 in Nominal, NPT End Style, 15 to 45 psig Pressure, Media: Air/Gas/Steam/Water, 4-1/4 in Inlet to Outlet Length, 10-1/4 in Top to Inlet Center, Stainless Steel Body, Neoprene/Nylon Softgoods
Body Material
Stainless Steel
End Style
NPT
Inlet to Outlet Length
4-1/4 in
Media
Air/Gas/Steam/Water
Nominal Size
1/2 in
Pressure Rating
15 to 45 psig
Series
455
Softgoods Material
Neoprene/Nylon
Top to Inlet Center
10-1/4 in
Trim Material
Stainless Steel
Type
Direct-Operated
- Operates with minimum inlet pressure of 5 PSIG
- Pressure balanced valve and seat for more precise control of downstream pressure
